丹佛斯过滤器FIA15-250型
FIA型过滤器有直角和直通型两种结构，安装方便，易于拆解和清洁，它的精心设计提供了X佳的流动工况。FIA型过滤器安装在自控装置、泵和压缩机之前，可以减少系统的故障停机和设备磨损。
过滤网及网格均由不锈钢制成，清晰容易，使用寿命长，过滤网流通面积大、阻力损失小，使清晰的时间间隔长，过滤网安装维修方便，无额外密封垫片需要安装，FIA型过滤器可以安装磁性插件一吸引铁屑，可以保护过滤网、延长清洗时间，在需要特别清洁的场合，还可安装50μ的过滤袋。每只过滤器上都清楚的表明了型号、尺寸及工作条件。
技术数据：介质温度：-600~+150℃；压力范围：X大工作压力：40bar；接口形式：DIN焊接接口，ANSI焊接接口；过滤器壳体：过滤器壳体材料为特殊耐低温钢，能在低温下运行；过滤网：过滤网及网格材料为不锈钢；过滤网尺寸及选择：过滤网有100u，150u，250u，500u
型号：过滤器壳体：FIA15D-148H3051/148H3085,FIA15A-148H3063/148H3097,FIA20D-148H3052/148H3086,FIA20A-148H3064/148H3098,FIA25D-148H3053/148H3087,FIA25A-148H3065/148H3099,FIA32D-148H3054/148H3088,FIA32A-148H3066/148H3100,FIA40D-148H3055/148H3089,FIA40A-148H3067/3101,FIA50D-148H3056/148H3090,FIA50A-148H3068/148H3102,FIA65D-148H3057/148H3091,FIA65A-148H3069/148H3103,FIA80D-148H3058/148H3092,FIA80A-148H3070/148H3104,FIA100D-148H3059/148H3093,FIA100A-148H3071/148H3105,FIA125D-148H3060/148H3094,FIA125A-148H3072/148H3106,FIA150D-148H3061/148H3095,FIA150A-148H3073/148H3107,FIA200D-148H3062/148H3096,FIA200A-148H3074/148H3108,FIA250D-148H3171,FIA250A-148H3173,FIA300D-148H3172,FIA300A-148H3174 过滤网：FIA15D/FIA15A/FIA20D/FIA20A-148H3122(100u)/148H3124(150u)/148H3126(250u）/148H3128（500u）,FIA25D/FIA25A/FIA32D/FIA32A/FIA40D/FIA40A-148H3123(100u)/148H3125(150u)/148H3127(250u）/148H3129（500u）,FIA50D/FIA50A-148H3157(100u)/148H3130(150u)/148H3138(250u）/148H3144（500u）,FIA65D/FIA65A-148H3131(150u)/148H3139(250u）/148H3145（500u）,FIA80D/FIA80A-148H3119(150u)/148H3120(250u）/148H3121（500u）,FIA100D/FIA100A-148H3132(150u)/148H3140(250u）/148H3146（500u）,FIA125D/FIA125A-148H3133(150u)/148H3141(250u）/148H3147（500u）,FIA150D/FIA150A-148H3134(150u)/148H3142(250u）/148H3148（500u）,FIA200D/FIA200A-148H3135(150u)/148H3143(250u）/148H3149（500u）,FIA250D/FIA250A-148H3175(250u）/148H3177（500u）,FIA300D/FIA300A-148H3176(250u）/148H3178（500u）
磁棒：FIA50-2464+595，FIA65-100-2464+596，FIA125-200-2464+597 排污阀件：FIA50-200-2412+634 过滤包：FIA50-148H3150,FIA65-148H3151,FIA80-148H3152,FIA100-148H3153,FIA125-148H3154,FIA150-148H3151,FIA200-148H3152
